Product Overview

Name: mBot2
Type: Educational Robotics Kit

Key Features

• CyberPi Integration:

• Full-color display

• Speaker

• Microphone

• Light sensor

• Gyroscope

• LED strips

• In-built Wi-Fi + Bluetooth for internet connectivity

• AI and IoT functionalities including speech recognition, voice synthesis, account cloud broadcast, LAN broadcast, and data upload to Google Sheets.

• mBot2 Shield:

• In-built rechargeable li-ion battery (2500mAh)

• Two ports for encoder motors

• Two ports for DC motors

• Four ports for servos

• Compatibility with LED strips and Arduino analog/digital sensors

• USB Type-C Cable:

• Connects CyberPi to the software for coding or to the shield for power.

• Ultrasonic Sensor 2:

• 8 ambient lights

• Precise distance measurement

• Injection-moulded casing for protection

• Quad RGB Sensor:

  • Detects lines and colors simultaneously

  • Quad channel design for precise intersection detection

  • Ambient lights for reduced false identification

  • Injection-molded casing for protection

  • 180 Optical Encoder Motor:

  • Torque: 1.5Kg·cm

  • Speed: 200RPM

  • Detection accuracy: 1°

  • Stable mechanical power delivery

  1. Master Control CyberPi:

  • Processor performance: 240MHz

  • ROM: 448KB

  • SRAM: 520KB

  • Processor core: dual-core Xtensa 32-bit LX6

  • SPI Flash: 8MB

  • Multithreading: support

  • Number of programs: up to 8

  • Python support: Live and Upload modes

  • Communication: Bluetooth + WiFi

  • Onboard sensors: light sensor, microphone, gyroscope, accelerometer

  • Onboard output: 1.44-inch full-color display

  2. Shield:

  • Battery capacity: 2500mAh

  • Discharge rate: 3C

  • Power rating: 27.75W

  • Encoder motor ports: 2

  • DC motor ports: 2

  • Servo ports: 4

  • LED strip compatible ports: 2 (shared with servo port)

  • Arduino compatible ports: 2 (shared with servo port)

  • Electronic extension modules: recommended up to 10

  3. Ultrasonic Sensor 2:

  • Casing: plastic

  • In-built chip: yes

  • Number of ambient lights: 8

  4. Quad RGB Sensor:


  • Casing: plastic

    Line-following sensors: 4

    Color sensors: 4 (embedded in line-following sensors)

    Light sensors: 4 (embedded in line-following sensors)

    Fill light: visible light

    Ambient light calibration: yes
