Me Line Follower V2
Makeblock Me Line Follower V2
Designed for the line following robotics. It has two sensors on the module and each sensor contains two parts – an IR emitting LED and an IR sensitive phototransistor. It can output a digital signal to Arduino so the robot can reliably follow a black line on a white background or vice versa.
Detecting range: 1~2cm
Dimensions：2.4cmx4.8cm
The dual line following sensor (hereinafter referred to as the line following module) is specially designed for line following robots. It contains two sensors, each of which has an infrared emitting LED and an infrared sensing phototransistor. After installing this module, the robot can move along black lines on a white background, or move along white lines on a black background. This module has the advantages of fast detection speed and simple circuit. The module interface is blue-colored, indicating that it is controlled by dual digital ports and needs to be connected to the blue-identified interface on the Makeblock motherboard.
Product Features:
- Comes with an Arduino library for easy programming.
- Easy wiring with 6 Pin RJ25 interface. 2.54mm breakout pins for connecting with jumper wires.
- Labeled with a blue tag and compatible with Me–Base Shield
- 16mm interval M4 mounting holes, compatible with Makeblock beams.
- A power indicator LED and two sensor state indicator LED.
Instructions for use:
It can be combined with the main control board of the RJ25 platform (such as mCore, Orion, etc.) to create some interesting examples, such as line-following cars, cliff-stopping cars, etc.
